Crane traveling mechanism, cabin and electric controlling system
- Lifting speed: 5-15M/MIN
- Trolley running speed: 20-40M/MIN
- Crane running speed: 50-100M/MIN
- Working duty: A5-A7
- Control method: cabin control/wire rope remote control
- Protection grade: IP54
- Insulation grade: F
- Colour: request
- Power supply: 3 phase 380V 50hz or request
Features and Advantages:
1. Appearance: compact size, building headroom low light self-weight.
2. Adapt to the environment: mechanical processing workshop, metallurgical plant auxiliary workshops, warehouses, the field and power stations of transport, assembly and maintenance and handling.
3. Working temperature: – 25 degrees ~ 40 degrees.
4. Banned items: banned in inflammable, explosive, corrosive environment in use.
5. Classification: light and medium.
6. Operating methods: The ground operation and in the driver’s cabin.
7. The cabin: Open-style and closed style
Note: It’s not suitable for lifting blazing & melting metal or toxicant as well as explosion- proof or insulating working conditions.
Crane Advantages
– Light dead weight
– High performance components with economical price
– Easy maintenance and Easy replacement of components
– Low cost of transportation cost and fast installation
– Top Quality and super performance with reliability
– High Efficiency and best return of the investment
Safety Device
1. Top quality longtime bearing polyurethane materials buffer
2. Lifting limit switch and traveling limit switch
3. Current overload protection system
4. Voltage lower protection function
5. Emergency stop system
6. Zero voltage protection
7. Weight overload limiter
