    HVG OVERHEAD CRANE 0001

    Overhead crane systems is prohibited to use the equipment in the combustible, explosives environment.

    • Lifting speed: 5-15M/MIN
    • Trolley running speed: 20-40M/MIN
    • Crane running speed: 50-100M/MINWorking duty: A3-A5
    • Control method: cabin control/wire rope remote control
    • Protection grade: IP54
    • Insulation grade: F
    • Colour: request
    • Power supply: 3 phase 380V 50hz or request

    Features and Advantages:

    1. Light working duty. Light dead weight, light wheel-pressure.
    2. Competitive price of Hengyuan single girder eot crane.
    3. Tight dimensions, low building headroom, light dead weight and light wheel load.

    Technical specification:

    • Technical data
    Crane Travelling Device Travelling speed (m/min) 20 30 45 60 75
    Reducer ratio 58.95 39.42 26.38 19.37 15.88
    Motor Model ZDY21-4 ZDR12-4
    Power (kw) 2×0.8 2×1.5
    Rotation (r/min) 1380
    Lifting device Electric Hoist model single/double speed
    (Electric hoist) Lifting speed (m/min) 8, 0.8/8
    And hoist travelling device Lifting height (m) 6, 9, 12, 18, 24, 30
    Travelling speed (m/min) 20 (30)
    Motor Taper Squirrel-cage type
    Work duty A3- A5
    Power supply 380V, 50Hz, 3-Phase or on your request
    Rail type P24/38
