MOORING EQUIPMENT 0187
    • MOORING EQUIPMENT 0187
    HVG MARINE MOORING EQUIPMENT 0187

    HVG MARINE MOORING EQUIPMENT 0187: 16 Strand Mooring Rope

    • 1. Type: polyamide staple yarn(thread), polypropylene filament(thread), polyester etc.
    • 2. Features: its special braided structure and technology remarkably rise up the utilization rate of strength of fiber thus to make the rope have advantages of low elongation, wearing resistance, smooth and pliable toughness and simple operation, therefore it provides ideal product for special requirement for customers
    • 3. Applications: shipbuilding, ocean transportation, petroleum drilling, national defense, military industry as well as loading and unloading in harbors
    • 4. Packing: Packaged with bags, standard export carton or by customer requirments
    • 5. Our advantages: quality assurance, experienced staffs, professional service, competitive price, etc.
    • 6. Certifications: GL, ABS, CCS, ISO, NK, BV, LR, DNV, RS, etc.
    • 7. Notes: Special specification and marks can be made according to customers requirements



    Technical specification:

    • Main performance:
    • Parameter table
    Material Polyamide multifilament Polyamide yarn Polypropyle multifilament Polyester
    Spec.Density 1.14 not floating 1.14 not floating 0.91 floating 1.27 not floating
    Melting Point 215℃ 215℃ 165℃ 260℃
    Abrasion Resistance Very Good Very Good Medium Good
    U.V.resistance Very Good Very Good Medium Good
    Temperature resistance 120℃ max 120℃ max 70℃ max 120℃ max
    Chemical resistance Very Good Very Good Good Good
    Specification PA multifilament PA yarn PP multifilament Polyester
    Dia. Cir. Ktex KN Ktex KN Ktex KN Ktex KN
    20 2-1/2 247 87 247 73 189 69 303 76
    24 3 355 123 355 106 273 96 473 108
    28 3-1/2 484 164 484 140 373 127 590 143
    32 4 632 211 632 177 483 160 795 184
    36 4-1/2 800 264 800 220 614 201 1000 231
    40 5 987 323 987 265 756 243 1227 283
    44 5-1/2 1190 386 1190 318 924 292 1477 339
    48 6 1420 453 1420 372 1092 339 1750 400
    52 6-1/2 1670 527 1670 432 1281 393 2020 466
    56 7 1930 605 1930 495 1491 449 2386 538
    60 7-1/2 2220 690 2220 564 1712 513 2730 614
    64 8 2530 780 2530 637 1943 581 3090 694
    72 9 3200 976 3200 795 2457 729 3910 868
    80 10 3950 1188 3950 972 3045 897 4820 1059
