HVG MARINE VENTILATION EQUIPMENT 0021: Pre-heat Insulation Sleeve
Drawing
HVG MARINE VENTILATION EQUIPMENT 0021
Technical specification:
- Main Specification
|
Specification |
Internal duct d |
External duct d |
L |
Wgt.≈kg/piece |
|
PM80 |
80 |
100 |
90 |
0.33 |
|
PM100 |
100 |
125 |
90 |
0.40 |
|
PM125 |
125 |
150 |
90 |
0.49 |
|
PM150 |
150 |
175 |
90 |
0.58 |
|
PM160 |
160 |
185 |
90 |
0.61 |
|
PM175 |
175 |
200 |
90 |
0.67 |
|
PM200 |
200 |
225 |
90 |
0.76 |
|
PM250 |
250 |
275 |
90 |
1.50 |
|
PM300 |
300 |
325 |
90 |
1.79 |
Note: Thickness of insuulation: δ=12.5mm
