HVG MARINE LIFE-SAVING EQUIPMENT 0190

HVG MARINE LIFE-SAVING EQUIPMENT 0190: Firebird Lifejacket (Solid Type) Chest – Jo Bird

The Firebird range of cabinets sets the standard by which others are measured and has consistently outperformed other products on the market. Individually accredited as a supplier to leading oil companies, Jo Bird & Co Ltd is also independently recognised for its quality standards under BS EN ISO 9001.

Used to Store Lifejackets/Immersion Suits
Lloyds Register Type Test Approved
Manufactured From 3-4mm Nominal Thickness GRP
Quality Manufacture under BS EN ISO 9001 Standards
Various Sizes (Can Store Up To 12, 24 and 30 Lifejackets)
Lettering, Fire Retardancy and 6mm Thick GRP Options Available

Technical specification:

Typical Use: Storage of Inherently Buoyant Life Jackets (12 According To Type)
Typical Use: Storage of Inherently Buoyant Life Jackets (12 According To Type)
Typical Use: Storage of Inherently Buoyant Life Jackets (24 According To Type)
Typical Use: Storage of Inherently Buoyant Life Jackets (24 According To Type)
Typical Use: Storage of Inherently Buoyant Life Jackets (30 According To Type)
Typical Use: Storage of Automatic Life Jackets (54 According to Type).
Typical Use: Storage of Lifejackets/Survival Suits (Quantity Depending on Type)
Typical Use: Storage of Immersion Suits (Quantity Depending on Type)

Approvals: Lloyds Register Type Test Approved Dimensions (mm): Height X Width: 950 x 600 Aperture (mm): 950H x 600W
Weight (Kg): 20
Colour: International Orange BS592 Material: 3-4mm
Nominal Thickness GRP
Lid Latches: 4 Stainless Steel Protex Clasps Optional Extras:
Lettering and Fire Retardancy

Approvals: Lloyds Register Type Test Approved Dimensions (mm): Height x Width x Depth: 510 x
970 x 625
Aperture (mm): 950H x 600W
Weight (Kg): 20
Colour: International Orange BS592
Material: 3-4mm Nominal Thickness GRP
Lid Latches: 2 Stainless Steel Protex Clasps Hinges: Stainless
Steel Piano Hinge
Optional Extras: Lettering, 6mm Thick GRP and Fire Retardancy

Approvals: Lloyds Register Type Test Approved Dimensions (mm): Height x Width x Depth: 690 x 1015 x 765
Aperture (mm): 1000H x 745W
Weight (Kg): 28
Colour: International Orange BS592
Material: 3-4mm Nominal Thickness GRP
Lid Latches: 4 Stainless Steel Protex Clasps
Optional Extras: Lettering, 6mm Thick GRP and Fire Retar-
dancy

Approvals: Lloyds Register Type Test Approved Dimensions (mm): Height x Width x Depth: 690 x 1015 x 765
Aperture (mm): 1000H x 745W
Weight (Kg): 28
Colour: International Orange BS592
Material: 3-4mm Nominal Thickness GRP
Lid Latches: 2 Stainless Steel Protex Clasps Hinges: 2
Stainless Steel Piano Hinge
Optional Extras: Lettering, 6mm Thick GRP and Fire
Retardancy

Approvals: Lloyds Register Type Test Approved Dimensions (mm): Height x Width x Depth: 790 x 1195 x 808
Aperture (mm): 1160H x 780W
Weight (Kg): 37
Colour: International Orange BS592
Material: 3-4mm Nominal Thickness GRP
Lid Latches: 4 Stainless Steel Protex Clasps Optional Extras:
Lettering, 6mm Thick GRP and Fire Retardancy

Approvals: Lloyds Register Type Test Approved
IP Rating: IP56
Dimensions (mm): Height X Width X Depth: 2015 x 1390 x 600
Aperture (mm): 1756H x 1164W
Weight (Kg): 65
Colour: Green or Orange
Material: 3-4mm Nominal Thickness GRP
Door Catch: Stainless Steel Lever Handle with 3-Way
Locking Bars
Hinges: Stainless Steel “T” Hinge
Seal: EPDM Seal
Reinforcement: 150mm² Pads of 12mm Ply to Top Corners of Back
Optional Extras: Lettering, Fire Retardancy and 6mm
Thick GRP

Approvals: Lloyds Register Type Test Approved Dimensions (mm): Height x Width x Depth: 800 x 2385 x 885
Aperture (mm): 2298W x 670D
Weight (Kg): 53
Colour: International Orange BS592
Material: 3-4mm Nominal Thickness GRP
Lid Latches: 2 Stainless Steel Protex Clasps Hinges: Stainless Steel “T” Hinges
Optional Extras: Lettering, 6mm Thick GRP and Fire Retardancy

Approvals: Lloyds Register Type Test Approved Dimensions (mm): Height x Width x Depth: 900 x 2400 x 900
Aperture (mm): 2298W x 670D
Colour: International Orange BS592
Material: 3-4mm Nominal Thickness GRP
Lid Latches: 2 Stainless Steel Toggle Clasps Hinges: 3
Stainless Steel “T” Hinges
Optional Extras: Lettering, 6mm Thick GRP and Fire Retardancy
