HVG PIPES – PIPE FITTINGS 0085: Painted Alloy Steel Pipe Caps
| Nominal diameter： | DN15 ~ DN1400 |
| 2.Wall thickness： | 1.6 ~ 12mm |
| 3.Standard: | |
| American standard: ASTM A234 WPB, ANSI B16.9, ANSI B16.28, ANSI B16.11
Japanese standard: JIS B2311, JIS B2312 |
|
| 4. Material: | |
| Carbon steel: A234WPB, A106, A105, Q235, ST37.2, GB10#, GB20# Stainless steel: SUS321, 304.304L, 306, 306L, 317L Alloy steel: 16Mn, 16MnR, 12CrMoV, 10CrMo910, Cr5Mo, 15CrMo, WB36, P51 |
|
| 5.Application: Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc | |
| 6.Finish: Satin, Polish, Painted, Brush | |
| 7.Connection: thread, weld, | |
