HVG MARINE STEEL 0101

HVG MARINE STEEL 0101: Super High Strength Shipbuilding Steel Plate

Super high strength shipbuilding steel plate is a kind of marine steel plate which is used for shipbuilding and offshore platforms. This plate features ultimate high strength. Its tensile strength is from 530MPa to 940MPa, and its nominal upper yield strength is from 420MPa to 690MPa. Its actual strength is over nominal strength in general. We provide you a full selection of steel grades, such as AB/AQ43, AB/FQ47, AB/DQ51, AB/EQ63, AB/FQ70… We can customize the plate size for you, if you have any special requirement. Our super high strength shipbuilding steel plates are certified by renowned classification societies, such as ABS, CCS, DNV, GL, LR, RINA,BV, KR, NK. If you want to know more details, welcome to contact us.

Plate Sizes

Thickness Range: 6~350mm
Width Range: 900~4850mm
Length Range: 3000~25000mm

Technical specification:

Available Super High Strength Shipbuilding Steel Plate

Adopted Standard	Steel Grade
ABS Grade	AB/AQ43, AB/AQ43N, AB/DQ43, AB/DQ43N, AB/EQ43, AB/EQ43N, AB/FQ43, AB/FQ43N, AB/AQ47, AB/AQ47N, AB/DQ47, AB/DQ47N, AB/EQ47, AB/EQ47N, AB/FQ47, AB/FQ47N, AB/AQ51, AB/DQ51, AB/EQ51, AB/FQ51, AB/AQ56, AB/DQ56, AB/EQ56, AB/FQ56, AB/AQ63, AB/DQ63, AB/EQ63, AB/FQ63, AB/AQ70, AB/DQ70, AB/EQ70, AB/FQ70
BV Grade	BVAH420, BVDH420, BVEH420, BVFH420, BVAH460, BVDH460, BVEH460, BVFH460, BVAH500, BVDH500, BVEH500, BVFH500, BVAH550, BVDH550, BVEH550, BVFH550, BVAH620, BVDH620, BVEH620, BVFH620, BVAH690, BVDH690, BVEH690, BVFH690
CCS Grade	CCSAH420 CCSDH420, CCSEH420, CCSFH420, CCSAH460, CCSDH460, CCSEH460, CCSFH460, CCSAH500, CCSDH500,CCSEH500, CCSFH500, CCSAH550, CCSDH550, CCSEH550, CCSFH550, CCSAH620, CCSDH620, CCSEH620, CCSFH620, CCSAH690, CCSDH90, CCSEH690, CCSFH690
DNV Grade	NV A420, NV D420, NV E420, NV F420, NV A460, NV D460, NV E460, NV F460, NV A500, NV D500, NV E500, NV F500, NV A550, NV D550, NV E550, NV F550, NV A620, NV D620, NV E620, NV F620, NV A690, NV D690, NV E690, NV F690
GL Grade	GL-A420, GL-A420TM, GL-D420, GL-D420TM, GL-E420, GL-E420TM, GL-F420, GL-F420TM, GL-A460, GL-A460TM, GL-D460, GL-D460TM, GL-E460, GL-E460TM, GL-F460, GL-F460TM, GL-A500, GL-D500, GL-E500, GL-F500, GL-A550, GL-D550, GL-E550, GL-F550, GL-A620, GL-D620, GL-E620, GL-F620, GL-A690, GL-D690, GL-E690, GL-F690
KR Grade	KRAH43, KRDH43, KREH43, KRFH43, KRAH47, KRDH47, KREH47, KRFH47, KRAH51, KRDH51, KREH51, KRFH51, KRAH56, KRDH56, KREH56, KRFH56, KRAH63, KRDH63, KREH63, KRFH63, KRAH70, KRDH70, KREH70, KRFH70
LR Grade	LRAH42, LRDH42, LREH42, LRFH42, LRAH46, LRDH46, LREH46, LRFH46, LRAH50, LRDH50, LREH50, LRFH50, LRAH55, LRDH55, LREH55, LRFH55, LRAH63, LRDH63, LREH63, LRFH63, LRAH70, LRDH70, LREH70, LRFH70
NK Grade	KA43, KD43, KE43, KF43, KA47, KD47, KE47, KF47, KA51, KD51, KE51, KF51, KA56, KD56, KE56, KF56, KA63, KD63, KE63, KF63, KA70, KD70, KE70, KF70
RINA Grade	RINA-A420, RINA-D420, RINA-E420, RINA-F420, RINA-A460, RINA-D460, RINA-E460, RINA-F460, RINA-A500, RINA-D500, RINA-E500, RINA-F500, RINA-A550, RINA-D550, RINA-E550, RINA-F550, RINA-A620, RINA-D620, RINA-E620, RINA-F620, RINA-A690, RINA-D690, RINA-E690, RINA-F690
