HVG MARINE CABLE 0027

HVG MARINE CABLE 0027: FA-DPY Shipboard Power and lighting cable 0.6/1KV

Applications

For fixed installations on ships and offshore-units in all locations.
Flame-Retardant, Double core, EP rubber insulated, PVC sheathed Shipboard Power Cable.

FA-DPY Shipboard Power and lighting cable 0.6/1KV Cable Construction

1.Conductor:Double core,Stranded tinned annealed Copper wires Class 2,JIS C 3410. (D)
2.Insulation:85°C (EPR),Ethylene Propylene Rubber. (P)
3.Cabling:-Insulated conductors shall be cabled.
- Flame retardant & non-hygroscopic fillers may be used.
- Suitable tape(s) may be applied on the cabled core.
4.Sheath:(PVC),Polyvinyl Chloride,Black color. (Y)
5.Core indentification:Black,White

FA-DPY Shipboard Power and lighting cable 0.6/1KV Standard

1.Design guide:JIS C 3410(1999)
2.Flame retardant:IEC 60332-1 & IEC 60332-3 Category A(FA-Type)
3.Cold bend/impact:CSA 22.2 No.03(-35oC)(Cold Type)

Conductor	S(D,T)	Tinned annealed stranded copper, class 2 according to IEC 60228
Conductor screen		Semi-conducting compound
Insulation	P	85°C EPR as per IEC 60092-351
Cabling		Insulated conductors shall be cabled. Flame retardant & non-hygroscopic fillers may be used
Sheath	Y	PVC as per JIS C 3401
Core identification		1C Black 2C Black, White 3C Black, White, Red
Outer sheath color		Black
