    HVG JIB CRANE 0003

    Wall Mounted Jib Crane

    •  manually and electric
    •  Included
    •  Included
    •  Included
    •  Included
    •  Siemens or CHINT brand
    •  Passed
    •  Passed

    Features and Advantages:

    1. Simple installation of wall cantilever jib crane can be mounted on wall, no special floor space required.
    2. Shorten loading time, improve work efficiency. With a jib crane, workers can lift, quickly transport and precisely deposit all kinds of work pieces at any time.
    3. Easy handing, lighten laboring work It can relieve the strain of physically demanding work on your staff. The risk of injuries or accidents when handing heavy or unwieldy parts is considerably reduced.
    4. High quality with good price of our wall traveling jib cranes.

    Technical specification:

    • Jib Crane Technical Data
    Model BZD0.5 BZD1 BZD2 BZD3 BZD5
    Lift capacity t 0.5 1 2 3 5
    Max. horizontal throw m 2.6 3.6 2.9-3.9 3.8 3.7
    Max. radius of gyration m 3.6 4.5 4.5 5 5
    Max. overturning moment t/m 3 6 12 18 27
    angle of revolution degree 180
    Lift speed normal m/min 8 (4)
    slow m/min 0.8 (0.4)
    Travel speed m/min 20
    angle of revolution speed m/min 1 0.75 0.7 0.9 0.6
